Filling valves with load cells
Range of applications
- Dairy products in the high and low-acid range
- Products with ingredients which could influence a flow meter
- Measuring system independent of fat content
- Particles up to 5 x 5 x 5 millimetres
- Fibres up to 2 x 10 mm
Technical features
- Non-contact full-jet filling
- Load cells with neck-handling for determining the liquid quantity
- Two different filling speeds via product-gentle double-stroke seat valve
- Non-turbulent closing of the filling valves thanks to double-stroke seat valve
- Product feed from above via a sliding ring manifold
- Sterilisation with steam
NWJ: Net weight filling, Weighing cell, full Jet
Filling valve
SIP-Kappe
Umschaltventil
Produktauslaufventil
Steuerzylinder Ventilkegel
Aseptischer Bereich
Wägezelle
Hydraulische Abdichtung „Wasserschloss“
Ventilkegel
Pneumatikzylinder
Zentralkessel
Benefits to you
- High microbiological safety
- Very precise fill quantities – regardless of the product characteristics
- Optimum flow behaviour
- Smooth filling process which is gentle on the product
- Minimum product loss
- Quick and media-efficient disinfection
- No CIP distributor needed
